Product Description

🔧 Key Specifications:

• Expanded Size: 9000mm × 6220mm × 2480mm

• Internal Dimensions: 8540mm × 6060mm × 2240mm

• Folded Size: 9000mm × 2200mm × 2480mm

• Floor Area: 55㎡

• Net Weight: 3.75 tons

• Capacity: 3–6 people

• Power Supply: 12KW / 220V / 50Hz

🛠️ Frame & Structural Components:

• Main Frame (Fully Galvanized)

• 80×140×3.0mm square tube

• 2.5mm bending for beams and columns

• 210×150×160mm galvanized hanging head

• Side Frame

• Top: 40×80×1.5mm P-shaped tube

• Bottom: 60×80×2.5mm square tube

• 130mm galvanized folding hinge

• Protective Coating
  Electrostatic spray + white plastic powder finish

🧱 Roof, Wall, and Floor:

• Roof:
  T50mm EPS color steel plate + 0.4mm corrugated veneer

• Ceiling:
  200-type ceiling panel

• Wall Panels:
  Side walls: T65mm EPS
  Partition: T50mm EPS

• Flooring:
  Center floor – 18mm fireproof cement fiber
  Side floors – 18mm bamboo plywood

🚪 Doors & Windows:

• Sliding window: 920×920mm

• Steel door: 840×2030mm

⚡ Electrical System:

• 32A leakage protector

• Lighting: Bull 30×30 flat lamp + large ceiling light

• Sockets: Standard 3-hole & 5-hole international outlets (customizable)

• Light Switch: Double open or single key switch

• Wiring: Pre-installed for lighting, air conditioning, and general use (certification adaptable)

📦 Container Loading:

One 40HQ shipping container can load 1 complete set of this 30FT expandable house.

✅ Why Choose Our 30FT Folding House?

• Extra-large layout (55㎡) for multi-person use

• Heavy-duty galvanized steel frame for long life

• Foldable for compact transport

• Full interior system pre-installed – plug & play

• Perfect for temporary or long-term modular housing
