Product Description

🔧Product Overview:

• Expanded Size: 11800mm × 6020mm × 2480mm

• Internal Dimensions: 11540mm × 6060mm × 2240mm

• Folded Size: 11800mm × 2200mm × 2480mm

• Floor Area: 72㎡

• Net Weight: 4.6 tons

• Capacity: 3–6 people

• Power Supply: 12KW / 220V / 50Hz

🛠️ Structural Features:

• Main Frame (Fully Galvanized)

• 80×140×3.0mm square tubes with 2.5mm bending

• Galvanized hanging head: 210×150×160mm

• Steel column with 2.5mm bending

• Side Frame

• Top: 40×80×1.8mm P-shaped tube

• Bottom: 60×80×2.5mm square tube

• 130mm galvanized hinge

• Protective Coating
  Electrostatic spray molding with straight white plastic powder

🧱 Roofing, Walls & Flooring:

• Roof:
  T50mm EPS sandwich panel + 0.4mm corrugated veneer

• Ceiling Panels:
  200-type ceiling

• Walls:
  Side walls: T65mm EPS
  Partition: T50mm EPS

• Flooring:
  Center floor – 18mm fireproof cement fiberboard
  Sides – 18mm bamboo plywood

🚪 Doors & Windows:

• Sliding window: 920 × 920mm

• Steel door: 840 × 2030mm

⚡ Electrical Configuration:

• 32A leakage protector

• Lighting: Bull 30×30 flat lamp + large ceiling lamp

• Sockets: International 3-hole & 5-hole (customizable to local standards)

• Switches: Double open or single key

• Wiring: AC port, general socket, lighting outlet (region-customizable)

🧰 Accessories Included:

Top corner line, skirting line, corner wrapping, waterproof tape, sling, structural adhesive, and glue gun — everything pre-installed and ready to use.

📦 Container Loading:

1 × 40HQ container can load 1 full set of the 40FT expandable house.

✅ Why Choose Our 40FT Folding House?

• Maximum space: 72㎡ single-unit layout

• Heavy-duty frame for long-term deployment

• Complete system: electrical, windows, flooring, structure — all in one

• Foldable for transport, easy to install on arrival

• Ideal for on-site housing, mobile offices, or remote accommodation
