Product Description

🔧 Product Specifications:

• Expanded Size: 5900mm × 6420mm × 2450mm

• Internal Dimensions: 5740mm × 6260mm × 2250mm

• Folded Size: 5900mm × 2200mm × 2450mm

• Floor Area: 38㎡

• Net Weight: 3.1 tons

• Capacity: 2–4 persons

• Power Requirement: 12KW (220V, 50Hz)

🛠️ Frame & Structure Details:

• Main Frame:
  80×100×3.0mm square tubes with galvanized coating and 2.0mm bending parts
  Anti-detachment hanging hook included for secure handling

• Side Frame:
  50×100×2.5mm top frame, 40×80×1.8mm P-shaped tube, 130mm galvanized hinge

• Protective Finish:
  Electrostatic spray coating with white plastic powder for corrosion resistance

🧱 Paneling & Construction:

• Roof Panels:
  T50mm EPS sandwich panel + 0.4mm corrugated veneer
  Wing roof: T100mm EPS panel + 0.4mm corrugated veneer

• Wall Panels:
  T65mm EPS sandwich panel for outer walls, T50mm for partitions
  Interior ceiling: 200-type ceiling plate

• Flooring:
  Center: 18mm fireproof cement fiberboard
  Sides: 18mm bamboo plywood

🚪 Doors & Windows:

• Sliding plastic steel window: 920×920mm

• Single steel door: 840×2030mm

⚡ Electrical System:

• 32A leakage protector

• Integrated lighting: Bull 30*30 flat lamp, large ceiling lamp

• Standard 2.5–6² sockets (customizable per region)

• Double switch or single key switch (configurable)

• Pre-installed wiring for air conditioner, lighting, and standard loads

🧰 Accessories:

Includes: corner line, skirting line, wrapping strips, glue gun, sling, adhesive, and structural supports — all pre-installed and ready for use.

📦 Container Loading:

1×40HQ container can load up to 2 complete 20FT flat-pack houses, maximizing shipping efficiency.

✅ Why Choose This Unit?

• Flat-top design offers extra headroom and usable interior space

• Full steel frame construction ensures durability and load-bearing strength

• Fast deployment with foldable frame and factory pre-assembled components

• Plug-and-play electrical system, ready for immediate use

• Ideal for modular living, project camps, and temporary housing
